Extract QR Codes From PDF Files Using Apryse SDK

namespace Program

{

   class Program

   {

      static void Main(string[] args)

      {

         PDFNet.Initialize("Place license key here");



         PDFNet.AddResourceSearchPath("Path to BarcodeModule Lib");



         if (!BarcodeModule.IsModuleAvailable())

         {

            Console.WriteLine("");

            Console.WriteLine("Unable to run BarcodeTest: Apryse SDK Barcode Module not available.");

            Console.WriteLine("---------------------------------------------------------------");

            Console.WriteLine("The Barcode Module is an optional add-on, available for download");

            Console.WriteLine("at https://dev.apryse.com/. If you have already downloaded this");

            Console.WriteLine("module, ensure that the SDK is able to find the required files");

            Console.WriteLine("using the PDFNet.AddResourceSearchPath() function.");

            Console.WriteLine("");

            return;

         }



         ExtractBarcodes();



      }



      static void ExtractBarcodes()

      {

         // Relative path to the folder containing test files.

         string inputPath = "../TestFiles/Barcode/";

         string outputPath = "../TestFiles/Barcode/output/";



         using (PDFDoc doc = new PDFDoc(inputPath + "barcodes.pdf"))

         {

            // Extract the barcodes as a JSON String

            string json = BarcodeModule.ExtractBarcodesAsString(doc);



            PDFDoc newDoc = new PDFDoc();



            JsonSerializerOptions options = new JsonSerializerOptions

            {

               PropertyNameCaseInsensitive = true,

               DefaultIgnoreCondition = System.Text.Json.Serialization.JsonIgnoreCondition.WhenWritingNull

            };



            Root? output = JsonSerializer.Deserialize<Root>(json, options);



            int currentPage = 1;

            foreach (Pages pages in output.Pages)

            {

               foreach (BarcodeData data in pages.Barcodes)

               {

                  List<double> rect = data.Rect;



                  if (rect != null)

                  {

                     Page page = doc.GetPage(currentPage);



                     double pageHeight = page.GetCropBox().Height();



                     // add padding to improve the look of the barcode pages

                     double padding = 10;



                     // convert coordinates from top-left origin to bottom-left origin and add padding

                     double x1 = rect.ElementAt(0) - padding;

                     double y1 = pageHeight - rect.ElementAt(3) - padding;

                     double x2 = rect.ElementAt(2) + padding;

                     double y2 = pageHeight - rect.ElementAt(1) + padding;



                     Rect convertedRect = new Rect(x1, y1, x2, y2);



                     ArrayList pageList = new ArrayList { page };





                     doc.PagePushBack(page);



                     Page clonedPage = doc.GetPage(doc.GetPageCount());



                     clonedPage.SetCropBox(convertedRect);



                     newDoc.PagePushBack(clonedPage);

                  }

               }

               currentPage++;

            }

            newDoc.Save(outputPath + "cropped.pdf", pdftron.SDF.SDFDoc.SaveOptions.e_linearized);



         }

      }



   }



 //Classes needed to deserialize the json output into

   public class BarcodeData

   {

      public double Angle { get; set; }

      public List<double> Rect { get; set; }

      public string Text { get; set; }

      public string Type { get; set; }

      public List<double> Vertices { get; set; }

   }



   public class Pages

   {

      public List<BarcodeData> Barcodes { get; set; }

   }



   public class Root

   {

      public List<Pages> Pages { get; set; }



   }

}
